CPU

Intel Socket 1200 for 10th and 11th Gen Intel Processors

Chipset

Intel Z590

Memory

4 x DIMM, 128GB max, DDR4 up to 5133+(OC) MHz Non-ECC, Un-buffered Memory *

Graphics

Intel UHD Graphics support †

Multi-VGA output support

DisplayPort 1.4 / HDMI (2.0 for 11th Gen, 1.4 for 10th Gen)

DisplayPort (1.4) Resolution

4096 x 2304 @ 60 Hz

HDMI 2.0 Resolution

4096 x 2160 @ 60 Hz (11th Gen CPU)

HDMI 1.4 Resolution

4096 x 2160 @ 30 Hz (10th Gen CPU)

Expansion Slots

1x PCIe 4.0 x16 (x16 and x4), 1 x PCIe 3.0 x16 (supports x4 mode), 2x PCIe 3.0 x1 ‡

First M.2 Socket

M.2_1 slot (Key M), type 2242/2260/2280/22110 **

Second M.2 Socket

M.2_2 slot (Key M), type 2242/2260/2280 ††

Third M.2 Socket

M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)

SATA 6Gb/s ports

4

Support Raid

0, 1, 5 and 10

LAN

Realtek 2.5Gb Ethernet

Wi-Fi

Intel Wi-Fi 6

Audio CODEC

Realtek ALC897 7.1 Surround Sound High Definition Audio CODEC

Back I/O Ports

PS2 combo port, 2x USB2.0 (black), DisplayPort, HDMI, 1x USB 3.2 Gen2x2 (Type-C), 1x USB 3.2 Gen2 (teal), 2.5Gb LAN, 2x USB3.2 Gen1 (blue), Optical S/PDIF out port, 5x Audio jacks, Wi-Fi module

USB Ports Motherboard headers

1x USB 3.2 Gen 1, for Type-C, 2x USB 3.2 Gen 1 header, 2x USB 2.0 headers

Accessories

Cables, 2x SATA 6Gb/s cables, I/O Shield, M.2 Rubber Package, 2x M.2 SSD screw packages, Support DVD, User manual

Form Factor

ATX, 305 x 234 mm

Trust Platform Module (TPM) Support

Yes

Thunderbolt Support

Yes
