CPU

Chipset

AMD X570

CPU Socket

AM4

Back Panel I/O

USB

4 x USB 3.1 / USB 3.2 Gen 1 Type-A

4 x USB 3.1 / USB 3.2 Gen 2 Type-A

Thunderbolt

2 x Thunderbolt 4

Display

1 x DisplayPort Input

1 x HDMI

Audio

5 x 3.5 mm

Ethernet / Controller

1 x Intel I225-V 2.5Gigabit

1 x Marvell AQtion AQC113CS 10GbE

Wi-Fi Antenna

2 x Connector

Buttons

BIOS Flashback

Memory

Memory Slots

4 x 288-Pin

Memory Support

DDR4 2133, 2400, 2666, 2800, 2933, 3000, 3200, 3400, 3466, 3600, 3733, 3866, 4000, 4133, 4266, 4400, 4600, 4800 MHz

Maximum Capacity

128 GB

Channel Architecture

Dual Channel

ECC Support

Non-ECC, ECC Unbuffered

Storage Expansion

SATA

6 x SATA III

M.2

2 x M Key 2242, 2260, 2280, 22110 (PCIe 4.0 x4, SATA (Unspecified))

1 x M Key 2242, 2260, 2280 (PCIe 4.0 x4)

RAID Support

RAID 0, 1, 10 (M.2)

Internal I/O

Expansion Slots

2 x PCIe 4.0 x16

1 x PCIe 4.0 x16 (x4 mode)

USB

1 x USB 3.1 / USB 3.2 Gen 2 Header (Supports 1 USB Type-C Port)

1 x USB 3.1 / USB 3.2 Gen 1 Header (Supports 2 USB Type-A Port)

3 x USB 2.0 Header (Supports 6 USB Type-A Port)

Air Cooling

2 x 4-Pin CPU

4 x 4-Pin System

Liquid Cooling

2 x 4-Pin Pump

Power Connectors

1 x 24-Pin Mainboard

1 x 8-Pin ATX

1 x 4-Pin ATX

Security

Chassis Intrusion, TPM Header

LED Header

4 x RGB

Diagnostics

Clear CMOS

Add-On

2 x Thunderbolt Card Header

Legacy

1 x Serial

BIOS

ROM

256 Mb

Front Panel I/O

I/O Connection Headers

AAFP, USB 3.1 / USB 3.2 Gen 1, USB 3.1 / USB 3.2 Gen 2

Audio

Audio Codec

Realtek S1220A (7.1-Channel)

Wireless

Bluetooth

5.2

Wi-Fi

Wi-Fi 6E (802.11ax) (MU-MIMO)

Software

Supported Operating Systems

Windows 10 (64-Bit)

Physical

Form Factor

ATX

Dimensions

9.6 x 12" / 24.4 x 30.5 cm
