CPU

Chipset

Intel Z690

CPU Socket

LGA 1700

Back Panel I/O

USB

1 x USB 3.2 Gen 2×2 Type-C

2 x USB 3.1 / USB 3.2 Gen 2 Type-A

1 x USB 3.1 / USB 3.2 Gen 1 Type-C

4 x USB 3.1 / USB 3.2 Gen 1 Type-A

Display

1 x DisplayPort

1 x HDMI

Audio

5 x 3.5 mm

1 x S/PDIF

Ethernet / Controller

1 x Intel 2.5Gigabit

Wi-Fi Antenna

2 x Connector

Memory

Memory Slots

4 x 288-Pin

Memory Support

DDR4

Maximum Capacity

128 GB

Channel Architecture

Dual Channel

ECC Support

Non-ECC Unbuffered

Storage Expansion

SATA

4 x SATA III

M.2

2 x M Key 2242, 2260, 2280, 22110 (PCIe 4.0 x4)

1 x M Key 2242, 2260, 2280 (PCIe 4.0 x4)

1 x M Key 2242, 2260, 2280 (PCIe 4.0 x4, SATA (Unspecified))

U.2

None

Optane Memory Support

Yes

RAID Support

RAID 0, 1, 5 (M.2)

RAID 0, 1, 5, 10 (SATA)

Internal I/O

Expansion Slots

1 x PCIe 5.0 x16

1 x PCIe 3.0 x16

1 x PCIe 3.0 x4

1 x PCIe 4.0 x1

USB

1 x USB 3.1 / USB 3.2 Gen 2 Header (Supports 1 USB Type-C Port)

1 x USB 3.1 / USB 3.2 Gen 1 Header (Supports 2 USB Type-A Port)

2 x USB 2.0 Header (Supports 4 USB Type-A Port)

Multi-GPU Support

None

Air Cooling

1 x 4-Pin CPU

1 x 4-Pin Assistant

4 x 3-Pin Chassis

Liquid Cooling

1 x 4-Pin Pump

Power Connectors

1 x 24-Pin Mainboard

1 x 8-Pin ATX

1 x 4-Pin ATX

Security

Chassis Intrusion

LED Header

4 x RGB

Audio

None

Diagnostics

Clear CMOS

Add-On

1 x Thunderbolt Card Header

Legacy

1 x Serial

BIOS

ROM

192 Mb

Front Panel I/O

I/O Connection Headers

AAFP, USB 3.1 / USB 3.2 Gen 1, USB 3.1 / USB 3.2 Gen 2

Audio

Audio Codec

Realtek (7.1-Channel)

Wireless

Bluetooth

5.2

Wi-Fi

Wi-Fi 6 (802.11ax)

Software

Supported Operating Systems

Windows 11 (64-Bit)

Windows 10 (64-Bit)

Physical

Form Factor

ATX

Dimensions

9.2 x 12″ / 23.4 x 30.5 cm
