Network Standard

IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IPv4, IPv6

Product Segment

N300 complete networking : 300 Mbps

Coverage

Medium homes

Data Rate

802.11n : up to 300 Mbps

Antenna

Fixed antenna x 2

Transmit/Receive

MIMO technology 2.4 GHz 2 x 2

Operating Frequency

2.4 GHz

Encryption

64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , WPS support

Management

UPnP, IGMP v1/v2/v3, DNS Proxy, NTP Client, DDNS, Port Trigger, Virtual Server, DMZ

WAN Connection Type

Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP

Utilities

Device discovery, Firmware restoration

Ports

RJ45 for 10/100 BaseT for WAN x 1, RJ45 for 10/100 BaseT for LAN x 4

Features

SmartQoS

- WMM

- User definable rules for IP/MAC/Port

- Upload and download bandwidth management

- ACK/SYN/FIN/RST/ICMP with highest priority

Parental Control

Guest Network : 2.4 GHz x 3

VPN server : IPSec Pass-Through, PPTP Pass-Through, L2TP Pass-Through, PPTP Server

IPTV support

Button

WPS Button, Power Button

LED Indicator

Power x 1

Wi-Fi x 1

WAN x 1

LAN x 1

Power Supply

AC Input : 110V~240V(50~60Hz)

DC Output : 12 V with max. 0.5 A current

OS Support

Windows® 10

Windows® 8.1

Windows® 8

Windows® 7

Windows® XP

Mac OS X

Linux

Dimensions

146 x 111 x 24 ~ mm (WxDxH)

Operation mode

Wireless router mode

Range extender mode

Access point mode
