CPU

Chipset

Intel Z690

CPU Socket

LGA 1700

Back Panel I/O

USB

1 x USB 3.2 Gen 2×2 Type-C

2 x USB 3.1 / USB 3.2 Gen 2 Type-A

1 x USB 3.1 / USB 3.2 Gen 1 Type-C

4 x USB 3.1 / USB 3.2 Gen 1 Type-A

Display

1 x DisplayPort

1 x HDMI

Audio

5 x 3.5 mm

1 x S/PDIF

Ethernet / Controller

1 x Intel 2.5Gigabit

Wi-Fi Antenna

2 x Connector

Memory

Memory Slots

4 x 288-Pin

Memory Support

DDR4 2133, 2400, 2666, 2800, 2933, 3000, 3200, 3333, 3400, 3466, 3600, 3733, 3866, 4000, 4133, 4266, 4400, 4600, 4800, 5000, 5133, 5333 MHz

Maximum Capacity

128 GB

Channel Architecture

Dual Channel

ECC Support

Non-ECC Unbuffered

Storage Expansion

SATA

4 x SATA III

M.2

2 x M Key 2242, 2260, 2280, 22110 (PCIe 4.0 x4)

1 x M Key 2242, 2260, 2280 (PCIe 4.0 x4)

1 x M Key 2242, 2260, 2280 (PCIe 4.0 x4, SATA (Unspecified))

U.2

None

Optane Memory Support

Yes

RAID Support

RAID 0, 1, 5 (M.2)

RAID 0, 1, 5, 10 (SATA)

Internal I/O

Expansion Slots

1 x PCIe 5.0 x16

1 x PCIe 3.0 x16

1 x PCIe 3.0 x4

1 x PCIe 4.0 x1

USB

1 x USB 3.1 / USB 3.2 Gen 2 Header (Supports 1 USB Type-C Port)

1 x USB 3.1 / USB 3.2 Gen 1 Header (Supports 2 USB Type-A Port)

2 x USB 2.0 Header (Supports 4 USB Type-A Port)

Multi-GPU Support

None

Air Cooling

1 x 4-Pin CPU

1 x 4-Pin Assistant

4 x 3-Pin Chassis

Liquid Cooling

1 x 4-Pin Pump

Power Connectors

1 x 24-Pin Mainboard

1 x 8-Pin ATX

1 x 4-Pin ATX

Security

Chassis Intrusion

LED Header

4 x RGB

Audio

None

Diagnostics

Clear CMOS

Add-On

1 x Thunderbolt Card Header

Legacy

1 x Serial

BIOS

ROM

192 Mb

Front Panel I/O

I/O Connection Headers

AAFP, USB 3.1 / USB 3.2 Gen 1, USB 3.1 / USB 3.2 Gen 2

Audio

Audio Codec

Realtek (7.1-Channel)

Wireless

Bluetooth

5.2

Wi-Fi

Wi-Fi 6 (802.11ax)

Software

Supported Operating Systems

Windows 11 (64-Bit)

Windows 10 (64-Bit)

Physical

Form Factor

ATX

Dimensions

9.2 x 12″ / 23.4 x 30.5 cm
