Pollo 8-Port AI PoE Network Switch With 2GB Uplink (PLN-1108MGB)

Product Name

PLN-1108MGB

Fixed Port

8*10/100Base-TX PoE ports (Data/Power) 2*10/100/1000Base-T uplink RJ45 ports (Data)

Ethernet Port

Port 1-8 can support 10/100Base-T X auto detect, port 9-10 can support 10/100/1000Base-T auto detect, full / half duplex MDI / MDI-X adaptive

Functional Switch

1*(Extender) Note: when the switch state changes, it must be restarted before the PoE switch function can take effect

Twisted Pair Transmission

10BASE-T: Cat3,4,5 UTP (≤250 meter) 100BASE-TX: Cat5 or later UTP (≤100 meter) 1000BASE-T: Cat5e or later UTP (≤100 meter)

Network Protocol

IEEE802.3 10BASE-T, IEEE802.3i 10Base-T IEEE802.3u 100Base-TX, IEEE802.3x

Forwarding Mode

Store and Forward (Full Wire Speed)

Switching Capacity

11.8Gbps (non-blocking)

Forwarding Rate@64byte

4.17Mpps

MAC

3k

Buffer Memory

2M

LED Indicator

Power: PWR (green), network: Link (yellow), PoE: PoE (green) Functional switch: EXTEND (green)

PoE Port

Port 1 to 8 IEEE802.3af/at @POE

Power Supply Pin

Default 1/2(+), 3/6(-), optional 4/5(+), 7/8(-) 2-pairs power supply

Max Power Per Port

30W, IEEE802.3af/at

Total PWR / Input Voltage

120W/ (AC100-240V)

Power Consumption

Standby <5W, Full load <120W

Power Supply

Built-in power supply, AC100~240V 50-60Hz 2.2A

Operation TEMP / Humidity

-20~+55°C;5%~90% RH Non condensing

Storage TEMP / Humidity

-40~+75°C;5%~95% RH Non condensing

Dimension (L*W*H)

195*130*40mm

Net /Gross Weight

<0.8kg / <1.2kg
