DISPLAY

Panel Size

75"

Panel Type

TFT LCD Module with DLED Backlight.

Display Area (mm)

1649.644(H) x 927.936(V)

Aspect Ratio

0.672917

Resolution

UHD 3840x2160(Pixels)

Colors

1.07B colors (10bit)

Brightness

400 nits (typ.)

Contrast Ratio

1200:1 Typ. , 5000:1 Max.(DCR enable)

Response Time

8ms

Viewing Angles

H = 178, V = 178 typ.

Backlight Life

50,000 Hours (Typ.)

Surface Treatment

Hardness: 9H with Anti-Fingerprint coating & Anti-Glare coating

PLATFORM

Processor

ARM Cortex A73*4

RAM

4GB (IFP7552-1A), 8GB (IFP7552-1B)

Storage

32GB (IFP7552-1A), 64GB (IFP7552-1B)

TOUCH

Type/ Tech

UFT (Ultra Fine Touch) Technology

Touch Resolution

32767 x 32767

Touch Point

Windows: 33 points touch, Android: 20 points touch

INPUT

HDMI

x2 (3840x2160@60Hz, HDCP2.2, CEC, Front x1, Side x1), x1 (3840x2160@60Hz, HDCP2.2, CEC, ARC, Side x 1)

RGB / VGA

x1 (1920x1080 @60Hz)

DisplayPort

x1 (3840x2160 @60Hz)

Audio

x1 (PC audio in)

RS232

x1

OPS

module slot x 1

WiFi

module slot x 1

OUTPUT

HDMI

x1 (on demand)

Audio

x1 (Earphone out)

SPDIF

x1 (optical)

LAN

RJ45

x1

USB

Type A

USB 2.0 x1(Side x1), USB 3.0 x4 (Front x2, Side x2, SmartPort™ USB)

Type B

x2, for touch

Type C

x1 (USB3.0, DP1.2 Alt Mode, 100M Ethernet, 60W PD)

BUNDLE SOFTWARE

Basic Annotation Software

myViewBoard WhiteBoard for Android

Pro Annotation Software

myViewBoard WhiteBoard for Windows (embedded in VPC)

Wireless Presentation

ViewBoard Cast & myViewBoard Display

SPECIAL FEATURES

All-in-one USB port

USB 3.0 x 4

Simple LAN sharing between IFP and slot-in device

10/100/1000M for Android and PC

Light Sensor

Yes

POWER

Voltage

100-240VAC +/- 10% Wide Range

Consumption

159.4W (Typ.) < 0.5 W (""Off"")

ERGONOMICS

Wall Mount (VESA® )

800 x 400

OPERATING CONDITIONS

Temperature (º C)

0°C to 40°C

Humidity

20% ~ 80% RH Non-Condensing

DIMENSIONS (W X H X D)

Physical (inch / mm)

1720.1 (W) x 1069.6 (H) x 118.4 (D) mm, 67.72 (W) x 42.11 (H) x 4.66 (D) inch
