Display
|
Panel Size: Wide Screen 24.0"(61.0cm) 16:9
|
|
Color Saturation : 72%(NTSC)
|
|
Panel Type : TN
|
|
True Resolution : 1920x1080
|
|
Pixel Pitch : 0.276 mm
|
|
Brightness(Max) : 350 cd/㎡
|
|
ASUS Smart Contrast Ratio (ASCR) : 100000000:1
|
|
Viewing Angle (CR≧10) : 170°(H)/160°(V)
|
|
Response Time : 0.5ms (GTG, Min.), 1ms (GTG, Ave.)
|
|
Display Colors : 16.7M
|
|
Flicker free
|
|
Refresh Rate(max) : 165Hz
|
|
Video Feature
|
Trace Free Technology : Yes
|
|
Skin-Tone Selection : 3 Modes
|
|
Color Temperature Selection : 4 Modes
|
|
GamePlus(modes) : Yes (Crosshair/Timer/FPS Counter/Display Alignment)
|
|
Low Blue Light : Yes
|
|
HDCP support : Yes
|
|
VividPixel : Yes
|
|
GameVisual :6 Modes(Scenery/Racing/Cinema/RTS/RPG/FPS/sRGB Modes)
|
|
Audio Features
|
Stereo Speakers : 2W x 2 Stereo RMS
|
|
Convenient Hotkey
|
Input Selection
|
|
GamePlus
|
|
5-way OSD Navigation Joystick
|
|
GameVisual
|
|
I/O Ports
|
Signal Input : HDMI(v1.4), DisplayPort 1.2, Dual-link DVI-D
|
|
Earphone jack : 3.5mm Mini-Jack (for HDMI & DisplayPort Only)
|
|
Signal Frequency
|
Digital Signal Frequency : DisplayPort：30 ~193 KHz (H) /60 ~165 Hz(V)
|
|
HDMI : 30 ~162 KHz (H) /50 ~144 Hz(V)
|
|
DVI: 30 ~160 KHz (H) /60 ~144 Hz(V)
|
|
Power Consumption
|
Power Consumption < 65W*
|
|
Power Saving Mode <0.5W
|
|
Power Off Mode <0.5W
|
|
Mechanical Design
|
Chassis Colors : Black
|
|
Tilt : +33°~-5°
|
|
Swivel : +90°~-90°
|
|
Pivot : +90°~-90°
|
|
Height Adjustment : 0~130 mm
|
|
VESA Wall Mounting : 100x100mm
|
|
Super Narrow Bezel Design : Yes
|
|
Security
|
Kensington lock
|
|
Dimensions
|
Phys. Dimension with Stand(WxHxD) : 561x(359~489)x211mm
|
|
Phys. Dimension without Stand (WxHxD) : 561x329.1x50.45mm
|
|
Box Dimension(WxHxD) : 664x415x221mm
|
|
Weight
|
Net Weight (Esti.) : 5.2 kg
|
|
Gross Weight (Esti.) : 7.7 kg
|
|
Accessories
|
Dual-link DVI cable (Optional)
|
|
Power cord
|
|
Power adapter
|
|
DisplayPort cable (Optional)
|
|
Quick start guide
|
|
HDMI cable (Optional)
|
|
Compliance and Standards
|
CB, CE, CU, ErP, FCC, J-MOSS, KCC, RoHS, UL/cUL, VCCI, WEEE, WHQL (Windows 10, Windows 8.1, Windows 7), MEPS, RCM, TUV Flicker-free , KC , eStandby, TUV Low Blue Light
|
|
Note
|
*measuring a screen brightness of 200 nits without audio/ USB/ Card reader connection
|
|
**Adaptive-Sync technology supported within 40Hz~165Hz for DP only
|
